16CH NVR 16xPOE 8MP/5MP/4MP H.265,HDMI 4K Output, 16x5MP H.265 POE Weatherproof VandalProof Bullet IP Cameras 6TB HDD

Package Content

• One 16CH 8MP/5MP/4MP H.264/H.265 16xPOE Network NVR
• 16x5MP 4K POE IP Camera
• 16x65FT Network Cable
• USB Mouse
• Smart P2P Auto Connection with QR Code Scan
• Smart Phone APP and PC Client Software
• CD with User Manual and Installation Guide
• One Year Full Warranty in USA

NVR Feature

• Video Input : 16CH IP POE . Total 16CH
• Video Resolution : 8MP/5MP/4MP/3MP/1080P/720P True HD High Resolution
• Live Frame Rate: 8M@480fps, 5M@480fps, 4M@320fps, 3M@480fps, 1080P@480fps
• Video Output : HDMI 4K
• Live View Resolution : 8MP/5MP/4MP/3MP/1080P/720P
• Compression: H.264/H.265
• Recording Bandwidth: Up to 320Mbps
• Recording Mode: Manual, Schedule, Event
• Search Mode: Date/time, Event, Motion
• Playback: Fast forward / backward (2x,4x,8x,16x), Slow forward(1/2x,1/4x,1/8x,1/16x) Step forward
• Monitoring: Webviewer, Mobile Viewer, CMS
• Smart P2P Auto Connection with QR Code Scan
• Free mobile App and PC client software
• Supported OS: Windows; Mac OS
• Mobile Device : iPhone, iPad, Android Smart Phone
• Supported Browser: IE, Firefox, Google Chrome, Safari
• Protocol Support: TCP/IP, UDP/IP, UDP
• Internal HDD: 2 SATA HDD capability up to 16TB
• USB Backup: 2xUSB2.0,1xUSB3.0
• Output: VGA and HDMI up to 4K
• Alarm trigger send images to designated e-mail
• Advanced motion detection function
• Audio: 1CH RCA in/ 1CH RCA out
• PTZ Control through RS-485
• Support PELCO-D PELCO-P protocol for PTZ Control
• Ethernet: 1 WAN RJ45 10/100/1000M Base-T / 16 LAN POE
• Power Input: 110-240V/3A, PoE:48V
• Dimensions (WxHxD): 380x50x340mm, Weight: 8kg
• Full compatible with Samsung IPC and NVR: NJ6516P, NJ6504P, NJ6508P, SNC-4241BE, SNR- D5401N

Camera Feature

• Imaging Device:5MP CMOS (1/3")
• Effective Pixels: 2952x1944
• Scanning System: Progressive
• Synchronization: Internal
• Horizontal Resolution: 1944TVL
• Audio In and Out
• Day/Night Color Cameras
• Advanced IR Cut Filter can capture up to 130ft in day timer and 80ft in complete darkness
• Min. Illumination: 0 Lux (IR LED ON)
• Camera Output: RJ45
• Focal Length: 2.8mm
• Max. Aperture Ratio: F2.1
• Angular Field of View 94
• Shutter Mode: Auto
• Gain Control: Auto
• White Balance: Auto
• Wide Dynamic Range: YES
• Contrast, Enhancement: Auto
• Digital Noise Reduction: 3DNR
• Flickerless: YES
• Day & Night: TRUE D/N, Auto
• IR Distance: 82ft(25M)
• Operating Temperature / Humidity: -10° ~ +50° (+14° ~ +129°) / Less than 90% RH
• Ingress Protection: IP66
• Input Voltage: POE/12VDC
• Power Consumption: 2W(IR LED OFF),3.2W(IR LED ON)
• Color / Material: White / Metal
• Dimensions (WxHxD): 69 x 145 x 72.3
• Weight: 0.4Kg.
• Full compatible with Samsung IPC and NVR: NJ6516P, NJ6504P, NJ6508P, SNC-4241BE, SNR-D5401N
